Description
Samsung 85" OH85N-S LH85OHNSLGB/XY Outdoor Display
- High visibility
- Water and Dust Resistant
- Low Reflection
- Magic Protection Glass - IK10-rated
- MagicINFO Player S7 - Content Management
- Powerful, protective security
Large displays optimised for DOOH
The OHN series has elevated the typical outdoor advertising experience with its bold and engaging content delivery for any bus stop or street billboard. The OHN series will make any business standout from the crowd with its immersive and high-quality images and content.
*Screen images simulated for illustrative purposes.
Unsurpassable visibility day and night
The OHN series allows for exceptional, consistent content delivery with 3,000nit brightness. With a built-in dimming sensor, the display automatically adjusts the brightness based on the external lighting environment, saving display operating expenses and power consumption.
*Screen images simulated for illustrative purposes
Easy-to-use management software
The embedded MagicINFO Player S6, backed by the powerful TIZEN operating system, boosts the display’s overall performance, allows for painless content management and ensures seamless transition and playback.
*License for MagicINFO must be purchased separately.
*Screen images simulated for illustrative purposes.
Built strong to endure impacts
The OHN series provides advanced safety through tempered Magic Protection Glass. It features durability that is IK10-rated, further proving its robust level of strength that can endure physical impact.
*Screen images simulated for illustrative purposes.
Resistant to outdoor elements
The OHN series is verified to perform in outdoor settings. IP56-rated protection ensures the OHN series will withstand physical impact as well as dust, humidity or other outdoor elements that could affect the display.
-----------------------------------------------------------
85" Specification
Specifications
Specifications Detail
Display
Diagonal Size
85"
Panel Type
VA
Resolution
3,840 x 2,160
Pixel Pitch (HxV)
0.4875(H) x 0.4875(V)
Brightness
3,000nit
Contrast Ratio
3,000:1
Viewing Angle (H/V)
178/178
Response Time
8ms
Colour Gamut
72 %
Glass Haze
0 %
H-Scanning Frequency
15~135KHz (HDMI), 30~135KHz (DP)
Maximum Pixel Frequency
594MHz (HDMI), 533.25MHz(DP)
V-Scanning Frequency
24~75Hz (HDMI), 30~75Hz (DP)
Contrast Ratio (Dynamic)
100,000:1
Connectivity
HDMI In
2
DP In
1
USB
1
Audio Out
Stereo Mini Jack
RS232 In
Stereo Mini Jack
RJ45 In
Yes
Power
Power Supply
AC 100 - 240 V (+/- 10 %), 50/60 Hz
Power Consumption (On Mode)
1800
Power Consumption (Sleep Mode)
0.5 W
Dimension
Set Dimension (WxHxD)
2004 x 1185 x 120 mm
Package Dimension (WxHxD) (mm)
2175 x 1383 x 495 mm
Weight
Set Weight
163 kg
Package Weight
211 kg
Operation Conditions
Temperature
-30℃~50℃
Humidity
10 ~ 80%, non-condensing
Mechanical Specification
Bezel Width
62
Glass Thickness
5T
Glass Film
AR, λ/4
Optional Feature
Protection Glass
Yes
Mount
No
Stand
No
Internal Player (MagicInfo)
MagicInfo Daisychain Videowall Support
No
Certification and Compliance
EMC
FCC (USA) Part 15, Subpart B Class B
Safety
CB (Europe) : IEC60950-1/EN60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore ) : PSB+IEC60950-1 NOM (Mexico ) : NOM-001-SCFI-1993 IRAM (Argentina ) : IRAM+IEC60950-1 SASO (Saudi Arabia ) : SASO+IEC60950-1 BIS(India) : IEC60950-1 / IS13252 NOM(Mexico) : Tuner : NOM-001-SCFI-1993 Tunerless : NOM-019-SCFI-1998 KC(Korea) : K 60950-1 EAC(Russia) : EAC+IEC60950-1 INMETRO(Brazil) : INMETRO+IEC60950-1 BSMI(Taiwan) : BSMI+IEC60950-1 RCM(Australia) : IEC60950-1/AS/NZS 60950-1 UL(USA) : cUL60950-1 CSA (Canada) : cUL TUV (Germany) : CE NEMKO (Norway) : CE
