NEC P525ULG Laser Projector

NEC P525ULG Projector	Throw Ratio: 1.23~2‎:1
Screen Size: (16:10)	Installation Distance
86" 185cm x 116 cm	2.3m to 3.7m
94" 203cm x 127cm	2.5m to 4m
109" 235cm x 147cm	2.9m to 4.7m
128" 276cm x 172cm	3.4m to 5.5m
139" 299cm x 187cm	3.7m to 5.9m
150" 303cm x 202cm	3.7m to 6m

5000 Lumens
FULL HD
Laser 20000 Hours
Quiet
H & V Lens Shift
20 Watt Speaker

Projector P525UL / P525WL

*Measured at centre area of projector screen

With NEC's new laser-phosphor projectors, you can enjoy colourful, crisp and impressive images with excellent quietness and minimal maintenance levels.

Functions and Features

Versatile, maintenance-free, entry-level installation projectors with excellent quietness

Filter-free Structure with NEC’s Original Cooling System

Filter-free Structure with NEC’s Original Cooling System NEC’ s Unique Sealed LCD Panel Cooling System

High dustproof performance is achieved by NEC's proprietary sealed jet impingement cooling structure. Due to its excellent dustproof performance, this projector does not have the cumbersome filters that ordinary LCD projectors require. The new laser-based LCD projector offers better TCO (total cost of ownership) with less maintenance.

Super Silent Design Utilising a Sealed Structure

The unique cooling system not only improves the dustproof performance but also reduces the noise of the fan. This quiet design achieves excellent quietness of 19 to 22 dB in ECO mode. Even in a very quiet meeting room or classroom, the presence of the projector is not felt.

Maintains the set brightness for a long time

The projector is equipped with a “constant brightness mode” that detects changes in brightness due to aging and automatically adjusts the output to keep the brightness constant. This makes it possible to project with stable brightness for a long time.

A Long-life Laser Diode is Provided in the Light Module

Advanced laser technology delivers a reliable light source up to 20,000 hours.

Self Colour Correction

This function compensates for the natural colour shift that occurs with age and adjusts to natural and suitable colours automatically according to the number of hours used.

Top of this page

Advanced Installation Functions and Connectivity

Lens Shift

Lens shift provides greater flexibility when determining the installation location.

Lens Shift

Tilt-free

The projector can be rotated freely (360°) to orient the image depending on the installation requirements.

Tilt-free

Portrait mode

Allows the projector to be rotated (and screen if necessary) to a vertical alignment so that portrait content can be viewed without black bars on the side when landscape mode is used.

Portrait mode

Built-in HDBaseT

HDBaseT

Simplify your installations with HDBaseT, which is optimised for video applications and supports uncompressed full HD digital video, audio, Ethernet, power and various control signals. With only a single cable (up to 100 m) to run, infrastructure and labour costs are reduced, installations are significantly easier, and there is no cable clutter to manage. With uncompressed HD video support, images have never been more stunning.

Dual HDMI Inputs

HDMI

The wide selection of inputs includes HDMI with HDCP for connecting to high-definition sources such as Blu-ray players, cable boxes, satellite receivers and personal computers.

Support for 4K Input

The built-in HDMI and HDBaseT input terminals support up to 4K video for display of ultrahigh resolution video.

Terminals

Top of this page

Advanced Networking Capabilities

MultiPresenter

This projector is compatible with the NEC MultiPresenter application, so multi-screen projection is possible via the network (wired LAN / wireless LAN).

Multi-screen Projection Function ^*1

The multi-screen projection function allows for the sharing of screens of multiple devices on various split-screen displays via a wireless or wired LAN. Display information from up to 50^*2 PCs, tablet PCs, smart phones, and other network connected devices on a multi-screen display of up to 16 screens. Easily share screens and information regardless of device or operating system.

Multi-screen Projection Function

Compatible OS

*1:Requires the optional wireless LAN module for wireless connection. PCs, smart phones and tablets require the download and installation of our MultiPresenter software.
*2:The connection of 50 devices to the network requires construction of a wireless LAN environment, such as the use of a separate access point.

Simultaneous Dual Image Display (PIP)

With this projector, it is possible to project two images with a single projector by displaying a small sub-display within the main display. Furthermore, the sub-display display position can be changed and the main display and sub-display images can be swapped.

Sub input position

It is possible to select from four sub-display positions.

Sub input position

Picture swap

The videos in the main display and sub-display will be switched.

Picture swap

Combination table of main display and sub-display terminals

		Sub-display
		HDMI 1	HDMI 2	HDBaseT	COMPUTER	LAN	USB-A
Main Display	HDMI 1		No	No	Yes	No	No
	HDMI 2	No		No	Yes	No	No
	HDBaseT	No	No		Yes	No	No
	COMPUTER	Yes	Yes	Yes		No	No
	LAN	Yes	Yes	Yes	Yes		No
	USB-A	No	No	No	No	No

Top of this page

Other Useful Functions and Features

20 Watt Built-in Speaker

The powerful 20-watt speaker provides sufficient volume in classrooms and meeting rooms.

Seamless Switching Function for Smoother Image Change

When the input signal is switched, the image displayed before switching is retained so that the new image can be displayed without a break.

[VIEWER] function to project still images saved on USB storage
Compatible with wired LAN / wireless LAN (option)
Quick power-on, Quick power-off supported
Quick start and Direct power-off / Quick power-off
Provides 2.0 A USB current for third-party wireless dongles
Keystone correction
+/– 30 degree Horizontal / Vertical keystone, Cornerstone, Pincushion correction supported
PIN security/Control panel lock/Security bar/Security slot
Virtual remote tool
Wall colour correction
DICOM simulation

Network Control

-NaViSet Administrator 2
-PC control
-Alert mail
-CRESTRON ROOMVIEW with emergency function and Extron XTP compatibility
-AMX BEACON
-PJLink
-HTTP server (projector adjustment)

Top of this page

Specifications

Model			NP-P605UL	NP-P525UL	NP-P525WL
Method			Three primary colour liquid crystal shutter projection
Specifications of main parts
	Liquid crystal panel	Size	0.64 inch LCD with MLA× 3 (aspect ratio: 16:10)
	Liquid crystal panel	Pixels ^*1	2,304,000 (1,920 dots× 1,200 lines)		1,024,000 (1,280 dots× 800 lines)
	Projection lenses	Zoom	Manual
		Focus	Manual
		Zoom ratio	1.6
		Throw ratio	1.23 to 2.0
		F-number/ focal length	F= 1.5 to 2.1 f= 17.2 mm to 27.6 mm
		Lens shifting	Manual ( H = +/ −29% / V= 0% to +60%)
	Light source		Blue Laser diode
	Light source (laser diode) life ^*2		20,000H
	Optical unit		Integrator, dichroic mirror, XDP
Light output ^{3 4}		ECO MODE [OFF]	6,000 lm (6,200 centre lm) ^*5	5,000 lm (5,200 centre lm) ^*5
		ECO MODE [ECO]	Approx. 60%
		ECO MODE [LONG LIFE]	Approx. 50%
Contrast ratio ^*4 (all white/all black)			600,000 : 1 with Light Adjust	500,000 : 1 with Light Adjust
Image size			30 to 300 inches
Colour reproduction			10-bit signal processing, 1.07 billion colours (Viewer, Network, 16.7 milion colours)
Quietness (ECO MODE [ECO] / ECO MODE [OFF])			19 dB / 25 dB to 28 dB (high bright)	22 dB / 24 dB to 27 dB (high bright)
Synchronisation range		Horizontal	15 to 100 kHz (RGB: 24 kHz or over)
Synchronisation range		Vertical	50 to 120 Hz
Max. display resolution (horizontal× vertical)			Up to 4K@30 Hz (3,840 x 2,160) with Advanced AccuBlend, Pixel clock frequency: less than 300 MHz (HDBaseT: 300 MHz)
Keystone correction		Horizontal	Manual, approx. ± 30 max degrees
Keystone correction		Vertical	Manual, approx. ± 30 max degrees
Input/output connectors
	Computer/ component	Video input	Mini D-Sub 15-pin× 1
		Audio input	Stereo mini jack× 1
		Audio output	Stereo mini jack× 1 (Selected from: Computer / HDMI)
	HDMI	Video input	Type A HDMI connector× 2
	HDMI	Audio input	Yes
	HDBaseT/ Ethernet Port	Video input	RJ45 × 1, 100BASE-TX / HDBaseT, Lip Sync Deep Colour, Colourimetry Support: RGB, YCbCr444, YCbCr422
	HDBaseT/ Ethernet Port	Audio input	Yes
	PC control connector		D-Sub 9-pin× 1 (4800 / 9600 / 19200 / 38400 bps)
	USB port		USB type A× 1 for USB (5.0 V/ 2.0 A power supply)
	Ethernet/LAN		RJ-45 × 1
	Wireless LAN Port (Optional)		USB× 1
Built-in speaker			20 W × 1
Usage environment			Operating temperature: 5 to 40°C ^*6, Operating humidity: 20 to 80% (with no condensation)
			Storage temperature: −10 to 50°C, Storage humidity: 20 to 80% (with no condensation)
			Operating altitude: 0 to 2,600 m (1,600 to 2,600 m: Set [FAN MODE] to [HIGH ALUTITUDE])
Power supply			100 − 240 V AC, 50/60 Hz
Power consumption		ECO MODE [OFF]	367 W (100 to 130 V) 357 W (200 to 240 V)	330 W (100 to 130 V) 320 W (200 to 240 V)	320 W (100 to 130 V) 312 W (200 to 240 V)
		ECO MODE [ECO]	261 W (100 to 130 V) 257 W (200 to 240 V)	240 W (100 to 130 V) 238 W (200 to 240 V)	232 W (100 to 130 V) 230 W (200 to 240 V)
		ECO MODE [LONG LIFE]	230 W (100 to 130 V) 227 W (200 to 240 V)	242 W (100 to 130 V) 240 W (200 to 240 V)	234 W (100 to 130 V) 232 W (200 to 240 V)
		NETWORK STANDBY	1.4 W (100 to 130 V) / 1.6 W (200 to 240 V)
		STANDBY ^*7	0.13 W (100 to 130 V) / 0.19 W (200 to 240 V)
Rated input current			5.5 A to 2.3 A	5.1 A to 2.1 A	5.0 A to 2.1 A
Dimensions (W× H× D)			480 ×122 ×407 mm (Net dimensions, not including protruding parts), 591 ×259 ×491 mm (Gross dimensions)
Weight			9.7 kg (Net weight), 12.8 kg (Gross weight, with box)

*1:Effective pixels are more than 99.99%.
*2:Time at which the laser light source is at half brightness; not a guaranteed time.
*3:This is the light output value (lumens) when [ECO MODE] is set to [OFF] and [PRESET] is set to [HIGH-BRIGHT]. The brightness decreases when [ECO MODE] is set to [ECO] or [LONG LIFE] ([ECO]: about 60%, [LONG LIFE]: about 50%). If any other mode is selected as the [PRESET] mode, the light output value may drop slightly.
*4:Compliant with ISO21118-2012.
*5:Measured at centre area of projector screen.
*6:35 to 40°C – “Forced eco mode”.
*7:Value as measured by NEC. All wired network ports are connected and active.

These specifications and the product’s design are subject to change without notice.

Top of this page

Lens shift range

Lens shift mechanism for adjusting the position of the projected image easily

Lens shifting range:
Vertical direction: +60%, −0%
Horizontal direction: ±29%

Lens shift range

Legend: V “Vertical” refers to the screen height and H “Horizontal” refers to the screen width.
The lens shift range is expressed as a ratio of height and width, respectively.

Top of this page

Throw distance and screen size

Screen size	Screen width (cm)	Screen height (cm)	Throw distance L (cm)		Height H (cm)
Screen size	Screen width (cm)	Screen height (cm)	Wide	Tele	0% V to 60% V
30"	64.6	40.4	76.5	125.8	−20.2 to 4.0
40"	86.2	53.8	103.1	168.9	−26.9 to 5.4
60"	129.2	80.8	156.4	255.0	−40.4 to 8.1
80"	172.3	107.7	209.8	341.1	−53.8 to 10.8
90"	193.9	121.2	236.4	384.2	−60.6 to 12.1
100"	215.4	134.6	263.1	427.3	−67.3 to 13.5
120"	258.5	161.5	316.4	513.4	−80.8 to 16.2
150"	323.1	201.9	396.4	642.6	−101.0 to 20.2
180"	387.7	242.3	476.4	771.8	−121.2 to 24.2
200"	430.8	269.2	529.7	857.9	−134.6 to 26.9
240"	516.9	323.1	636.4	1030.1	−161.5 to 32.3
270"	581.6	363.5	716.4	1159.3	−181.7 to 36.3
300"	646.2	403.9	796.4	1288.5	−201.9 to 40.4

*Stated throw distances are standard values.
*The values in the tables are design values and may vary.

Projector throw distance simulation
