Optoma Zu606TST Laser Projector
|Optoma Zu606TST Projector||Throw Ratio: 0.8:1|
|Screen Size:||Installation Distance|
|100" 221m x 125cm||1.7m|
|110" 244cm x 137cm||1.9m|
|120" 266cm x 149cm||2.1m|
|130" 288cm x 161cm||2.2m|
|140" 310cm x 174cm||2.4m|
|150" 332cm x 187cm||2.6m|
- 6000 Lumens
- 300,000:1 Contrast
- Full Hd Resolution
- Short Throw
- Laser Light Source
- Vertical & Horizontal Keystone
- Vertical Lens Shift
- 4 Corner Correction
- 2x HDMI Input
2x 10W Speaker
- IPX6X Dust Resistant Optical Engine
- 360° Installation and Portrait Mode
- Optional 3D
- Up to 20,000 Lamp Hours
- 3 Years Optoma Australia Warranty
Short-Throw for Small Spaces & Minimal Shadowing
The PE456USLG is a reliable laser projector with unique short-throw lens fits in tight spaces and significantly reduces shadows on the screen. This powerful projector generates a higher brightness level at 4,500 ANSI lumen and the vivid brilliance of 3 LCD technology.
With wireless presentation and screen sharing capability, versatile adjustability, and compatibility with leading control systems, the PE456USLG is feature packed for lecture rooms, training rooms and meeting rooms.
Powerful Performance – after startup images appear immediately with breakthrough laser technology, video processing/scaling supports 4K/30 content
Enjoy a Lower TCO – highest reliability, maintenance free operation, low power consumption and up to 20000 hours life; the Laser light source results in a significantly lower total cost of ownership.
More Flexible Installations – short-throw lens allows the projector to be placed closer to the projection surface which saves space and minimizes shadow.
Cost Saving Device Management – save effort whilst administrating all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.
High brightness professional laser projector
The ZU606TST-W is the smallest projector in its class. It delivers high brightness 6,000 lumens along with 4K and HDR compatibility. For added flexibility, this low maintenance projector features long-life laser technology, a 0.79:1 throw ratio, vertical lens shift and built-in 10W speakers.
Suitable for a wide variety of applications, the ZU606TST-W is perfect for anywhere that requires a clean and bright image including large venues, classrooms, lecture halls, museums and houses of worship.
Capable of receiving and displaying HDR meta data, Optoma HDR compatible projectors allow you to see far more detail and texture. Objects look more solid and life-like and the extra detail creates a greater sense of depth. It’s like looking through a window.
Industry leading long lifetime is achieved using Optoma’s DuraCore technology. Implementing advanced laser diode cooling techniques and an innovative dust resistant design.
Uncompromising, uncompressed Full HD video, audio, network and control commands all delivered on a single CAT- type cable capable up to 100 meters/328 feet without signal loss makes installation hassle-free. HDBaseT™ simplifies cabling requirements and reduces installation complexity saving both time and reducing costs.
IP6X Airtight optical engine
Independently tested and certified to IEC standard 60529 with an IP6X dust resistance rating. Outstanding dust resistance combined with exceptional brightness ensures industry leading durability; paramount for 24/7 maintenance free operation in challenging environments.
This feature allows the projector to be instantly powered on again, if it is accidentally switched off.
Vertical Lens Shift
Simplify installation with vertical lens shift, which provides a wider range of projector placement possibilities. This makes it easier to position the projector in your room and enables a wider range of screen size options.
PJLink protocol is incorporated into the projector allowing for easy installation with PJLink compatible control systems.
A built-in speaker offers excellent audio support and an easy setup without the need for costly external speakers
Ideal for digital signage applications; you can rotate your projector 90 degrees to project a portrait image.
Turn your projector into a smart display by connecting your smartphone or tablet with a single cable using MHL; now you can view presentations and documents, stream videos and share photos on the big screen.
This model is able to receive comands via telenet allowing for easy installation with Telnet compatible control systems.
Add more depth to your image with a high contrast projector. Compared to competing technology, Optoma DLP projectors provide you with brighter whites and ultra-rich blacks, images come alive and text appears crisp and clear - ideal for business and education applications.
Four corner correction
Adjust the keystone in both the vertical and horizontal plane. You can individually warp each corner of the image to create a perfectly square image. Ideal for image stacking, uneven walls or where projector placement is awkward and needs to be installed at an angle.
Auto Keystone automatically adjusts the trapezoid effect when the projector is off-axis to create an aligned image*.
*Auto keystone only adjusts the image in the vertical plane.
Featuring a wide range of options you can control and monitor the projector remotely.
Optoma projector’s come with an extensive set of RS232 commands making it simple and easy to manage using any control system.
• AMX compatible
Dynamic discovery protocol is incorporated into the projector allowing for easy installation with AMX control systems.
• Crestron RoomView
Using the compatible RoomView® software you can power on/off, monitor, manage and control up to 250 projectors at the same time from any computer
• Extron IPLink compatible
Allows for easy installation with Extron control systems
Use the USB-A port to power an HDMI dongle, such as Google Chromecast.
Optoma projectors can display true 3D content from almost any 3D source, including 3D compatible graphics cards, 3D broadcasting and the latest generation 3d media servers.
A powerful built-in speaker provides exceptional sound quality and an easy setup without the need for costly external speakers.
Use the USB-Power to power an HDMI dongle.
Stay in control of your presentation with AV mute. Direct your audience's attention away from the screen by blanking the image when not needed.
Auto power off
There may be instances when the projector is left running when not in use. To help save energy, the "auto power off" feature automatically turns off the projector after a set period of time if it is not being used
Direct power on
The projector will start up instantly when power is supplied to the unit. This eliminates the need to manually turn on the projector via the remote control or the keypad, ideal for use in rooms with a “master” power switch.
Direct power off
Power off your projector immediately or directly at the main power source. This means you don’t have to wait for the projector to cool down before turning it off.
Optoma projectors have been designed to operate 24 hours a day in standard orientation. Perfect for applications where prolonged periods of use is required. Subject to 24 hour terms and conditions.
24/7 Operation - standard lamp warranty applies. Projector warranty is based on standard business usage hours. For optimum performance Optoma recommends that your projector is turned off or placed in standby mode for 30 minutes every 24 hours to prolonging the life of your lamp.
Optoma projectors can display true 3D content from almost any 3D source, including 3D Blu-ray players, 3D broadcasting and the latest generation games consoles.
Native aspect ratio
Aspect ratio - compatible
Keystone correction - horizontal
Keystone correction - vertical
Has vertical auto keystone correction
Displayable colors (millions)
Horizontal scan rate
Vertical scan rate
24~ 85 Hz (120Hz for 3D)Hz
29.38" ~ 305.6" diagonal
Light source type
19.69" - 204.72"
Focal length (mm)
Vertical -100 ~ 120%
Yes - see documentation for details
Inputs 1 x HDMI 1.4a 3D support, 1 x HDMI 1.4a 3D support + MHL, 2 x VGA, 1 x Composite video, 1 x Mic 3.5mm, 1 x Audio 3.5mm, 1 x HDBaseT, 1 x S-Video
Outputs 1 x VGA, 1 x USB-A power 1.5A, 1 x Audio 3.5mm
Control 1 x RS232, 1 x 12V trigger, 1 x RJ45
Noise level (typical)
Noise level (max)
UHD, FHD, UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac
NTSC M/J, 3.58MHz, 4.43MHz PAL B/D/G/H/I/M/N, 4,43MHz SECAM B/D/G/K/K1/L, 4.25/4.4MHz 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz), 1080p(50/60Hz), 2160p(24/50/60Hz)
Side-by-Side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60
Security bar, Kensington Lock, Password protected interface
OSD / display languages
25 languages: Arabic, Czech, Danish, Dutch, English, Farsi, Finnish, French, German, Greek, Hungarian, Indonesian, Italian, Japanese, Norwegian, Polish, Portuguese, Romanian, Russian, Chinese (simplified), Spanish, Swedish, Chinese (traditional), Turkish, Vietnamese
5°C~40°C/41°F~104°F, max altitude 3000M/9843ft, max humidity 85%
Backlit ProAV remote
Watts per speaker
In the box
AC power cord
2x AAA batteries
Basic user manual
Optional wireless models
HDCast Pro, QuickCast Bundle, QuickCast starter kit
LAN - control
100V ~ 240V ± 10%, 50-60Hz
Power consumption (standby)
Power consumption (max)
Dimensions (W x D x H)
14.72" x 11.89" x 4.61"
