Description
LG 98" 98UM5K-B 4K Digital Signage
Brightness : 500 nit (Typ.)
Resolution : ULTRA HD (3,840 x 2,160)
Bezel : 17 mm (Even bezel)
Built-in Speaker (10 W + 10 W)
Interface : HDMI(3)/ DP/ DVI-D/ USB 2.0/ RS232C/ RJ45/ Audio/ IR
UHD Large Screen Signage Display with LG webOS Platform
*The image is simulated to enhance feature understanding. It may differ from actual use.
High Resolution
Delivering immersive viewing experience by 4 times higher definition picture quality than Full HD.
High Brightness
With a 500 cd/m²*, the UM5K series delivers content that can attract the attention of viewers and is a suitable display solution for retail and corporate applications.
* The images is stimulated to enhance feature understanding. It may differ from actual use.
* cd/m2 represents candela per meter squared.
* cd/m2 represents candela per meter squared.
High-Performance with webOS
LG webOS* platform enhances user convenience with intuitive GUI** and simple app development tools.
*webOS Signage is a web-based platform and provides an execution environment for web apps — Internet access is required to access the platform.
** GUI (Graphic User Interface) is a form of graphics-based operating system interface that uses icons, menus and a mouse (to click on the icon or pull down the menus) to manage interaction with the system.
** GUI (Graphic User Interface) is a form of graphics-based operating system interface that uses icons, menus and a mouse (to click on the icon or pull down the menus) to manage interaction with the system.
Built-in Speaker
Content will be enriched with sound effects from built-in speakers, without the need for purchasing or installing external speakers.
*Image dramatised for illustrative effect.
Compatible with AV Control System
The UM5K series has Creston Connected Certification, a function and network-based control system that is dedicated to meeting rooms and that meets a growing need in the corporate meeting space market.
*Internet connection required
SuperSign Solutions
SuperSign* (optional additional cost software license) is an integrated and intuitive content management solution for creative and organised digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
LG SuperSign CMS provides a service that works with external content (Streaming, Web page, Web video, etc.), and external content is not included in the solution.
* Annual license fee apply
* Annual license fee apply
PANEL
-
- Screen Size
- 98"
- Panel Technology
- ADS
-
- Back Light Type
- Direct
- Aspect Ratio
- 16:9
-
- Native Resolution
- 3840 x 2160 (UHD)
- Refresh Rate
- 60Hz
-
- Brightness (Typ.)
- 500 nit
- Contrast Ratio
- 1,200:1
-
- Dynamic CR
- 200,000 : 1
- Color gamut
- DCI-P3 88%↑
-
- Viewing Angle(H x V)
- 178 x 178
- Color Depth
- 1.07 Billion Colors (8 bits + FRC)
-
- Response Time
- 8ms (G to G)
- Surface Treatment(Haze)
- 25%
-
- Lifetime
- 30,000 Hrs (Min.)
- Operation Hours (Hours/Day)
- 16/7
-
- Portrait / Landscape
- No / Yes
MECHANICAL SPECIFICATION
-
- Bezel Color
- Black
- Bezel Width
- 17 mm (Even Bezel)
-
- Weight(Head)
- 78 kg
- Packed Weight
- 105 kg
-
- Monitor Dimensions (W × H × D)
- 2,198× 1,253 × 79.5 mm
- Carton Dimensions (W × H × D)
- 2,455 × 1,458 × 288 mm
-
- Handle
- Yes
- VESA™ Standard Mount Interface
- 800 × 400 mm
KEY FEATURE(HARDWARE)
-
- Internal Memory
- 16 GB
- Wi-Fi
- Built-in Wi-Fi
-
- Temperature Sensor
- Yes
- Auto Brightness Sensor
- Yes
-
- Acceleration(Gyro) Sensor
- Yes
- Local Key Operation
- Yes
-
- Power Indicator
- Yes
KEY FEATURE(SOFTWARE)
-
- webOS ver.
- webOS 6.0
- Local Contents Scheduling
- Yes
-
- Group Manager
- Yes
- USB Plug & Play
- Yes
-
- Fail Over
- Yes
- Booting Logo Image
- Yes
-
- No Signal Image
- Yes
- Local Network Sync
- Yes
-
- PIP
- Yes
- PBP
- Yes (4)
-
- Screen Share
- Yes
- Video Tag
- Yes (4)
-
- Play via URL
- Yes
- Tile Mode Setting
- Yes (Max. 15x15)
-
- Setting Data Cloning
- Yes
- SNMP
- Yes
-
- ISM Method
- Yes
- Auto Set ID
- Yes
-
- Status Mailing
- Yes
- Control Manager
- Yes
-
- Cisco Certi.
- Yes
- Crestron Inside
- Yes
-
- Smart Energy Saving
- Yes
- PM mode
- Yes
-
- Wake on LAN
- Yes
- Network Ready
- Yes
-
- Beacon
- Yes
- HDMI-CEC
- Yes
-
- SI Server Setting
- Yes
- webRTC
- Yes
-
- Pro:Idiom
- Yes
ENVIRONMENT CONDITIONS
-
- Operation Temperature
- 0 °C to 40 °C
- Operation Humidity
- 10% ~ 80%
POWER
-
- Power Supply
- AC 100-240 V ~, 50/60 Hz
- Power Type
- Built-In Power
POWER CONSUMPTION
-
- Typ./Max.
- 430 W / 560 W
- Smart Energy Saving (70%)
- 301 W
-
- DPM
- 0.5W
- Power Off
- 0.5 W
-
- BTU (British Thermal Unit)
- 1,467 BTU/Hr (Typ.), 1,911 BTU/Hr (Max)
SOFTWARE COMPATIBILITY
-
- Software Compatibility
- SuperSign CMS, SuperSign Control+, SuperSign WB, SuperSign Cloud, Promota (Not available for EU/CIS), Mobile CMS, LG ConnectedCare)
CONNECTIVITY
-
- Input
- HDMI (3 (HDMI1/2 : HDCP 2.2/1.4, HDMI3)), DP (HDCP 2.2/1.3), DVI-D (HDCP 1.4), Audio In, RS-232C (4 Pin Phone-jack), RJ45 (LAN), IR In, USB 2.0 Type A
- Output
- HDMI Out, Audio Out, RS-232C Out (4 Pin Phone-jack), Daisy Chain (Input HDMI, DP, DVI / Output HDMI)
SOUND
-
- Speaker
- Yes (10W X 2)
LANGUAGE
-
- Language
- English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkiye, Arabic, Polski
CERTIFICATION
-
- Safety
- CB/ NRTL
- EMC
- FCC Class "A" / CE / KC
-
- ErP
- Yes (NewErP)
ACCESSORY
-
- Basic
- Remote Controller(include battery 2ea), Power Cord, QSG, IR/Light sensor receiver, Regulation Book, Phone to RS233C Gender
