Display

Brightness (ANSI lumens)
3000
Resolution
4K UHD (3840×2160)
Native Aspect Ratio
16:9
Contrast Ratio (FOFO)
10,000:1
Display Color
30-bit (1.07 billion colors)
Light Source
Lamp
Light Source Life
a. Normal 4000 hrs, c. SmartEco 8000 hrs, d. LampSave 15000 hrs, b. ECO 10000 hrs
Optical

Throw Ratio
0.9~1.08
Zoom Ratio
1.2x
Lens
F/#=1.94~2.05;f=9.25~11.1 mm
Projection Offset (Full-Height)
110%
Keystone Adjustment
2D, (Auto) Vertical ± 30 degrees; Horizontal ± 30 degrees

Rec. 709 Coverage
96%
Picture Modes
3D, Bright, Cinema, Game, HDR, HDR Game, HLG, Living Room, Sport, User
Compatibility

Input Lag
16.7 ms (1080P 60Hz), 16.7 ms (4K 60Hz), 4.2 ms (1080P 240Hz), 8.3 ms (1080P 120Hz)
Resolution Support
VGA (640 x 480) to 4K UHD (3840 x 2160)
Horizontal Frequency
15K~135KHz
Vertical Scan Rate
23~120Hz
I/O Interface

HDMI in
(x2), HDMI-1 (2.0b/HDCP2.2), HDMI-2 (2.0b/HDCP2.2)
USB Type A
(x1), USB Type A-1 (2.0/Power Supply1.5A)
RS232 in (DB-9pin)
(x1)
Audio

Speaker
(x1), 5W Chamber
Audio out (3.5mm Mini Jack)
(x1)
HDMI Audio Return
Yes, eARC, Dolby Atmos
Environment

Operating Temperature
0~40℃
Power Supply
AC 100 to 240 V, 50/60 Hz
Typical Power Consumption (110V)
305W
Stand-by Power Consumption
<0.5W
Acoustic Noise (Typ./Eco.)(dB)
34/28 dBA
Accessories

Remote Control w/ Battery
RCV013
Power Cord (by region)
x1 (1.8M)
Quick Start Guide
(x1) 3L
Warranty Card (by region)
Yes
Universal Ceiling Mount
CM00G3, (Optional)
Dimension & Weight

Dimensions (WxHxD) (mm)
312 x110 x246
Net Weight (kg)
3.1
Dimensions (WxHXD) (inch)
12.2 x 4.3 x 9.6
Net Weight (lb)
6.83
Projection System

Projection System
DLP
